Panoramica tecnica
Telaio
Telaio:
Fourstroke 01 Premium Carbon with Autodrop Technology | APS Suspension System | 100mm Travel | Fully Guided Internal Cable Routing | Post Mount Disc | 12 x 148mm Boost Thru-Axle
Forcella:
Sospensioni
Sospensione Anteriore:
Fox Float 32 SC Factory | Kashima Coating
Sospensione Posteriore:
Fox Float DPS Factory | Kashima Coating
Lockoout in remoto:
DT Swiss Remote Lockout
Cockpit
Attacco Manubrio:
BMC MSM 01
Piega:
BMC MFB 01 Carbon | 760mm
Seat
Reggisella:
BMC Autodrop Integrated Dropper Seatpost | 80mm Drop
Sella:
Prologo Dimension NDR T4.0
Freni
Leve Freno / Pinze:
SRAM Level Ultimate
Dischi freno:
SRAM HS2
Diametro dischi:
160 / 160 S-M | 180 / 160 L-XL
Ruote
Cerchi:
DT Swiss XRC 1200 | 30mm Inner Width
Mozzi:
DT Swiss 180 Straightpull | Ratchet EXP 36
Pneumatici:
Vittoria Mezcal | 2.35"
Informazioni aggiuntive
Sezione max coperture:
62mm
Peso senza Pedali:
10.92 kg
Classificazione ASTM:
Level 3
Limite di peso massimale:
110kg
Regolamento sulla sicurezza generale dei prodotti (GPSR):
Avvertenze di sicurezza GPSR (UE)
Persona responsabile ai sensi del GPSR (UE)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | <172 | 172-182 | 180-188 | >188 |
| Reach | 437 | 457 | 477 | 500 |
| Stack | 584 | 592 | 600 | 615 |
| Bar Rise | 4 | 4 | 4 | 4 |
| Bar Sweep | 8° | 8° | 8° | 8° |
| Bar Width | 760 | 760 | 760 | 760 |
| BB Drop | 53 | 53 | 53 | 53 |
| Crank Length | 165 | 170 | 170 | 175 |
| Fork Length | 513 | 513 | 513 | 513 |
| Fork Rake | 44 | 44 | 44 | 44 |
| Front Center | 714 | 738 | 762 | 791 |
| Head Tube | 84 | 93 | 101 | 118 |
| Head Tube Angle | 66.5 | 66.5 | 66.5 | 66.5 |
| Rear Center | 432 | 432 | 432 | 432 |
| Seat Angle | 75.6 | 75.6 | 75.6 | 75.6 |
| Seat Tube | 420 | 440 | 470 | 510 |
| Seatpost Drop | 80 | 80 | 80 | 80 |
| Seatpost Length | 389 | 414 | 414 | 414 |
| Seatpost Offset | 0 | 0 | 0 | 0 |
| Standover Height | 725 | 725 | 725 | 725 |
| Stem Angle | -5° | -5° | -5° | -5° |
| Stem Length | 50 | 60 | 60 | 70 |
| Top Tube | 574 | 597 | 621 | 649 |
| Trail | 113 | 113 | 113 | 113 |
| Wheelbase | 1139 | 1171 | 1188 | 1218 |
