Panoramica tecnica
Telaio
Telaio:
URS Premium Carbon with Micro Travel Technology | Tuned Compliance Concept Gravel | Gravel+ Geometry | Internal Cable Routing | Fender and Rack Mounts | Flat Mount Disc | 12 x 142mm Thru-Axle
Sospensioni
Sospensione Anteriore:
Micro Travel Technology Suspension Fork | Premium Carbon Blades | 20mm Travel | Coil Spring & Hydraulic Damper | Fender Mounts | Flat Mount Disc | 12x100mm Thru-Axle
Sospensione Posteriore:
Micro Travel Technology Stays
Cockpit
Attacco Manubrio:
BMC MSM
Piega:
Easton EA70 AX
Seat
Reggisella:
URS 01 Premium Carbon D-Shaped Seatpost
Sella:
WTB SL8 Titanium
Gruppo
Guarnitura:
SRAM Force 1
Corona:
SRAM X01 Eaglerings
Pacco pignoni:
SRAM XG-1275 Eagle
Ingranaggi:
10-52T
Catena:
SRAM X01 Eagle
Cambio:
SRAM X01 Eagle AXS
Comandi:
SRAM Force eTap AXS HRD
Rapporti:
1 x 12
Movimento centrale:
PF86 Bottom Bracket
Freni
Leve Freno / Pinze:
SRAM Force eTap AXS HRD
Dischi freno:
SRAM Centerline X
Diametro dischi:
180 / 160mm
Ruote
Cerchi:
CRD-400 SL Carbon | Tubeless Ready | 40mm
Mozzi:
CRD-400 SL
Pneumatici:
WTB Raddler | 40mm
Informazioni aggiuntive
Sezione max coperture:
42mm measured tire
Classificazione ASTM:
Level 2
Limite di peso massimale:
120kg
Regolamento sulla sicurezza generale dei prodotti (GPSR):
Avvertenze di sicurezza GPSR (UE)
Persona responsabile ai sensi del GPSR (UE)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | <170 | 172-180 | 178-188 | 186-196 |
| Reach | 403 | 415 | 419 | 429 |
| Stack | 538 | 569 | 603 | 641 |
| Bar Drop | 120 | 120 | 120 | 120 |
| Bar Reach | 80 | 80 | 80 | 80 |
| Bar Width | 420 | 420 | 440 | 440 |
| BB Drop | 69 | 69 | 69 | 69 |
| Crank Length | 170 | 172.5 | 172.5 | 175 |
| Fork Length | 407 | 407 | 407 | 407 |
| Fork Rake | 45 | 45 | 45 | 45 |
| Front Center | 625 | 648 | 665 | 700 |
| Head Tube | 113 | 146 | 172 | 207 |
| Head Tube Angle | 70 | 70 | 70 | 70 |
| Rear Center | 425 | 425 | 425 | 425 |
| Seat Angle | 74 | 74 | 74 | 74 |
| Seat Tube | 431 | 459 | 492 | 527 |
| Seatpost Length | 330 | 380 | 430 | 430 |
| Standover Height | 748 | 778 | 810 | 846 |
| Stem Angle | 0 | 0 | 0 | 0 |
| Stem Length | 70 | 70 | 80 | 90 |
| Top Tube | 557 | 578 | 591 | 612 |
| Trail | 77 | 77 | 77 | 77 |
| Wheelbase | 1041 | 1064 | 1081 | 1105 |
