Descripción técnica
Cuadro
Cuadro:
Timemachine 01 Disc Premium Carbon with Vmax Aero Design and P2P Positioning SyStem | Internal Di2 Battery Mount | PF86 Bottom Bracket | Rear Storage | BoxAero Caliper Cover | Sliding Dropouts | Flat Mount Disc | 12 x 142mm Thru-Axle
Horquilla:
Timemachine 01 Disc Premium Carbon with Vmax Aero Design Hinge Design | Aero Caliper Cover | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Potencia:
BMC Flat Cockpit
Manillar:
BMC Flat Cockpit | Profile T4+ Carbon Extensions
Seat
Tija de Sillín:
Timemachine 01 Premium Carbon V-Max Aero Seatpost | 62mm Offset adjustment | P2P Dual-Mount Aeropost Configuration | Triathlon & Time Trialt
Sillín:
Fizik Mistica Mg
Transmisión
Platos y Bielas:
SRAM Force AXS
Platos:
48-35T
Potenciómetro:
Cassette:
SRAM Force XG-1270
Tamaño del cassette:
10-28T
Cadena:
SRAM Apex
Desviador Delantero:
SRAM Force eTap AXS
Cambio Trasero:
SRAM Force eTap AXS
Manetas de Cambio:
SRAM eTap AXS
Marchas:
2 x 12
Pedalier:
PF86 Bottom Bracket
Frenos
Pinzas de Freno:
SRAM S-900 Aero HRD Disc Brake
Discos:
SRAM Centerline X
Tamaño del disco:
160 / 160mm
Ruedas
Llantas:
DT Swiss ARC 1650 Carbon Disc | 62mm
Bujes:
DT Swiss ARC 1650 Disc
Neumáticos:
Pirelli P Zero Race
Accesorios
Información adicional
Paso de rueda:
27mm
Clasificación ASTM:
Level 1
Límite de peso del sistema:
110kg
Size | S | S-M | M-L | L |
---|---|---|---|---|
Rider Height | <170 | 172-180 | 178-188 | 186-196 |
Reach | 393 | 377 | 418 | 442 |
Stack | 480 | 515 | 515 | 556 |
Bar Drop | ||||
Bar Reach | ||||
Bar Rise | ||||
Bar Sweep | ||||
Bar Width | ||||
Base Bar Drop Flat Cockpit | +/- 80 | +/- 80 | +/- 80 | +/- 80 |
Base Bar Drop V-Cockpit | 85 | 85 | 85 | 85 |
Base Bar Reach Flat Cockpit | 619 | 612 | 653 | 670 |
Base Bar Reach V-Cockpit | 617 | 611 | 652 | 669 |
BB Drop | 58 | 68 | 68 | 68 |
BB Drop (SLACK) | ||||
BB Drop (STEEP) | ||||
BB Height (SLACK) | ||||
BB Height (STEEP) | ||||
Chainstay | ||||
Crank Length | 165 | 170 | 170 | 172.5 |
LT | BB Drop (SLACK) | ||||
LT | BB Drop (STEEP) | ||||
LT | BB Height (SLACK) | ||||
LT | BB Height (STEEP) | ||||
LT | Chainstay | ||||
LT | Fork Length | ||||
LT | Fork Rake | ||||
LT | Frame Size | ||||
LT | Front Center (SLACK) | ||||
LT | Front Center (STEEP) | ||||
LT | Head Tube | ||||
LT | HT Angle (SLACK) | ||||
LT | HT Angle (STEEP) | ||||
LT | Reach (SLACK) | ||||
LT | Reach (STEEP) | ||||
LT | Rider Height | ||||
LT | Seat Tube | ||||
LT | ST Angle @750mm Saddle Height (SLACK) | ||||
LT | ST Angle @750mm Saddle Height (STEEP) | ||||
LT | ST Angle Actual (SLACK) | ||||
LT | ST Angle Actual (STEEP) | ||||
LT | ST Angle Effective (SLACK) | ||||
LT | ST Angle Effective (STEEP) | ||||
LT | Stack (SLACK) | ||||
LT | Stack (STEEP) | ||||
LT | Stand Over Height (80 in Front of BB) | ||||
LT | Stand Over Height (Lowest Point) | ||||
LT | Top Tube (SLACK) | ||||
LT | Top Tube (STEEP) | ||||
LT | Wheelbase (SLACK) | ||||
LT | Wheelbase (STEEP) | ||||
ST | BB Drop (SLACK) | ||||
ST | BB Drop (STEEP) | ||||
ST | BB Height (STACK) | ||||
ST | BB Height (STEEP) | ||||
ST | Chainstay | ||||
ST | Fork Length | ||||
ST | Fork Rake | ||||
ST | Frame Size | ||||
ST | Front Center (SLACK) | ||||
ST | Front Center (STEEP) | ||||
ST | Head Tube | ||||
ST | HT Angle (SLACK) | ||||
ST | HT Angle (STEEP) | ||||
ST | Reach (SLACK) | ||||
ST | Reach (STEEP) | ||||
ST | Rider Height | ||||
ST | Seat Tube | ||||
ST | ST Angle @750mm Saddle Height (SLACK) | ||||
ST | ST Angle @750mm Saddle Height (STEEP) | ||||
ST | ST Angle Actual (SLACK) | ||||
ST | ST Angle Actual (STEEP) | ||||
ST | ST Angle Effective (SLACK) | ||||
ST | ST Angle Effective (STEEP) | ||||
ST | Stack (SLACK) | ||||
ST | Stack (STEEP) | ||||
ST | Stand Over Height (80 in Front of BB) | ||||
ST | Stand Over Height (Lowest Point) | ||||
ST | Top Tube (SLACK) | ||||
ST | Top Tube (STEEP) | ||||
ST | Wheelbase (SLACK) | ||||
ST | Wheelbase (STEEP) | ||||
Fork Length | 374 | 374 | 374 | 374 |
Fork Rake | 45 | 45 | 45 | 45 |
Frame Size | ||||
Front Center | 580 | 578 | 619 | 649 |
Front Center (SLACK) | ||||
Front Center (STEEP) | ||||
Head Tube | ||||
Head Tube Angle | 71.5 | 71.5 | 71.5 | 71.5 |
HT Angle (SLACK) | ||||
HT Angle (STEEP) | ||||
Pad Reach Flat Cockpit | 388 - 474 | 381 - 467 | 422 - 508 | 438 - 524 |
Pad Reach V-Cockpit | 366 - 530 | 359 - 522 | 400 - 563 | 417 - 580 |
Pad Stack Flat Cockpit | 535 - 610 | 555 - 630 | 555 - 630 | 595 - 670 |
Pad Stack V-Cockpit | 593 - 643 | 616 - 665 | 616 - 665 | 656 - 705 |
Reach (SLACK) | ||||
Reach (STEEP) | ||||
Rear Center | 400 | 400 | 400 | 400 |
Saddle Height Range | 630 - 780 | 660 - 850 | 660 - 850 | 700 - 880 |
Seat Angle | 71.5 - 80.8 | 71.5 - 80.8 | 71.5 - 80.8 | 71.5 - 80.8 |
Seat Tube | 495 | 550 | 550 | 592 |
Seatpost Drop | ||||
Seatpost Length | ||||
Seatpost Offset | 27 / 9 / -9 / -27 | 27 / 9 / -9 / -27 | 27 / 9 / -9 / -27 | 27 / 9 / -9 / -27 |
ST Angle @750mm Saddle Height (SLACK) | ||||
ST Angle @750mm Saddle Height (STEEP) | ||||
ST Angle Actual (SLACK) | ||||
ST Angle Actual (STEEP) | ||||
ST Angle Effective (SLACK) | ||||
ST Angle Effective (STEEP) | ||||
Stack (SLACK) | ||||
Stack (STEEP) | ||||
Stand Over Height (80 in Front of BB) | ||||
Stand Over Height (Lowest Point) | ||||
Standover Height | 755 | 797 | 797 | 838 |
Stem Angle | ||||
Stem Length | ||||
Top Tube | ||||
Top Tube (SLACK) | ||||
Top Tube (STEEP) | ||||
Trail | 60 | 60 | 60 | 60 |
Wheelbase | 972 | 968 | 1009 | 1039 |
Wheelbase (SLACK) | ||||
Wheelbase (STEEP) |
