Technology
Technical Overview
Frameset
Frame:
Fourstroke LT AMP Carbon | APS Suspension System | 120mm Travel | Integrated Battery | Fully Guided Internal Cable Routing | Post Mount Disc | 12 x 148mm Boost Thru-Axle
Suspension
Front Suspension:
RockShox SID SL Select+
Rear Suspension:
RockShox SIDLUXE Select+
E-System
Drive Unit:
TQ-HPR50 Drive Unit
Battery Pack:
TQ Battery | 360 Wh
Display:
TQ VO2 Display | 2" O-LED | Bluetooth / ANT+
Drive Unit Control:
TQ V01 Remote
Charger:
TQ-HPR50 4A Charger
Cockpit
Stem:
Truvativ Atmos 6K
Handlebar:
BMC MRB 03 | 760mm
Seat
Seatpost:
X-Fusion Manic
Saddle:
Fizik Antares R7
Drivetrain
Crankset:
Praxis eCrank
Chainrings:
34T
Cassette:
SHIMANO Deore SLX (CS-M7100)
Cassette Size:
10-51T
Chain:
SHIMANO CN-M6100
Rear Derailleur:
SHIMANO XT (RD-M8100)
Shifters:
SHIMANO Deore XT (SL-M8100) | Rapidfire Plus
Gears:
1 x 12
Brakes
Brake Levers / Calipers:
SHIMANO BL-M7100 Levers | BR-M7120 Calipers
Rotors:
SHIMANO SM-RT66
Rotor Size (F/R):
180 / 180mm
Wheels
Rims:
DT Swiss M 1900 | 30mm Inner Width
Hubs (F/R):
DT Swiss 370 | Ratchet LN18
Tires:
Maxxis Rekon 2.4" | EXO TR
Additional Information
Tire Clearance:
60mm
ASTM Classification:
Level 3
System Weight Limit:
120kg
Size | S | M | L | XL |
---|---|---|---|---|
Rider Height | <172 | 172-182 | 180-188 | >188 |
Reach | 437 | 457 | 476 | 496 |
Stack | 594 | 605 | 615 | 627 |
Bar Rise | 15 | 15 | 15 | 15 |
Bar Sweep | 9 | 9 | 9 | 9 |
Bar Width | 760 | 760 | 760 | 760 |
BB Drop | 40 | 40 | 40 | 40 |
Crank Length | 165 | 170 | 170 | 175 |
Fork Length | 531 | 531 | 531 | 531 |
Fork Rake | 44 | 44 | 44 | 44 |
Front Center | 725 | 751 | 775 | 800 |
Head Tube | 90 | 102 | 113 | 125 |
Head Tube Angle | 66.5 | 66.5 | 66.5 | 66.5 |
Rear Center | 435 | 435 | 435 | 435 |
Seat Angle | 77 | 77 | 77 | 77 |
Seat Tube | 420 | 430 | 470 | 490 |
Seatpost Drop | 125 | 150 | 150 | 170 |
Standover Height | 730 | 730 | 730 | 730 |
Stem Angle | 6 | 6 | 6 | 6 |
Stem Length | 40 | 50 | 50 | 60 |
Top Tube | 574 | 597 | 620 | 644 |
Trail | 115 | 115 | 115 | 115 |
Wheelbase | 1157 | 1178 | 1202 | 1227 |
